SHIVISION-S0439-HD 3D All around view Monitoring system for Bus

SHIVISION-S0439-HD 3D All around view Monitoring system for Bus

Product Name
HD 3D All around view Monitoring system for Bus
Model No
SVS-S04039
Product Category
all around view sysytem
Release Date
March 4,2017
Warranty Terms
1 year of warranty
Payment Term
T/T &Paypal&western union

Product display



undefined
undefined
undefined


SHIVISION S0439 3D HD 960P AHD Waterproof IP68 BUS Driver Assistance 360 Around View System


Product Keywords


  • 01
    Four 180 degrees ultra wide fish-eye cameras,High video recording resolution up to 1080p.
  • 02
    3D video de-interlacing and noise reduction technology for CVBS signal decoding.
  • 03
    Seamless video merging based on dual core ARM CPU and hardware high efficiency acceleration engine.
undefined
  • 04
    Support alternative recording media for TF card and USB disk.Smart power managements to save automobile’s battery .
  • 05
    The simplest calibration steps with calibration tape and packing box,and system applicable for almost all types of vehicle which including Buses, Trucks, Lorries, Limousines, Tank and even Jumbo Jets.
  • 06
    Typical length of the vehicle is 5.5m, 6.5m,10m&13m.


Key Specifications


Video Interface

BMW Mini connector

Input / Output Impedance

75Ω

Amplitude Typical

1Vpp, 1.2Vpp Maximum

Bandwidth

27M

Sampling Frequency

74.25MHZ

Resolution

1280X720@30fps

Signal standard

AHD1.0(Nextchip)

SNR

70dB

High beam

Optional

Left/Right Turning Blinker

Yes

Reversing Lamp

Yes

BM250E

Bosch

Algorithm

H.264 Baseline@L3.1

Resolution

1080p@15fps

Bitrates

5Mbps,3Gbyte/Hour

Recording Media

USB Disk(High Priority)/TF

TF CARD

32G SDIO3.0/SDIO2.0

USB Disk

Max 128G USB2.0

4-CH DVR + SVM mode

350mA

4-CH DVR mode

600mA

Sleep Mode

<10mA

Dimension

123*81*25mm(Host Metal box)

Waterproof rating

IP68

Normal Working

-30℃~+85℃

Storage

-40℃~+105℃

Relative Humidity

0~95%

Working Voltage

9.5V~36V
